- RS品番:
- 872-2402
- メーカー型番:
- PIC16F917-I/P
- メーカー/ブランド名:
- Microchip
120 海外在庫あり - 通常4営業日でお届け
単価: 購入単位は10個
¥944.20
(税抜)
¥1,038.62
(税込)
個 | 単価 | 1チューブあたりの価格* |
---|---|---|
10 - 290 | ¥944.20 | ¥9,442.00 |
300 - 2990 | ¥871.60 | ¥8,716.00 |
3000 - 3990 | ¥813.60 | ¥8,136.00 |
4000 - 4990 | ¥784.40 | ¥7,844.00 |
5000 + | ¥755.30 | ¥7,553.00 |
* 購入単位ごとの価格
- RS品番:
- 872-2402
- メーカー型番:
- PIC16F917-I/P
- メーカー/ブランド名:
- Microchip
その他
詳細情報
PIC16F913/914/916/917/946 8-Bit Flash Microcontrollers
The PIC16F range of microcontrollers from Microchip are 8-bit MCUs that incorporate Microchips PIC® architecture into a variety of pin and package options, from space efficient 14-pin devices to feature-rich 64-pin devices. Devices with Baseline, Mid-Range or Enhanced Mid-Range architecture are available with numerous different peripheral combinations, giving designers flexibility and choice for their applications.
The PIC16F913/914/916/917/946 family of microcontrollers is based upon Microchips Mid-Range core with an 8 level deep hardware stack and 35 instructions. These MCUs provide up to 5 MIPS, up to 14 Kbytes program memory, up to 352 bytes RAM and EEPROM of 256 bytes. On board is a configurable oscillator factory calibrated to ±1% accuracy.
The PIC16F913/914/916/917/946 family of microcontrollers is based upon Microchips Mid-Range core with an 8 level deep hardware stack and 35 instructions. These MCUs provide up to 5 MIPS, up to 14 Kbytes program memory, up to 352 bytes RAM and EEPROM of 256 bytes. On board is a configurable oscillator factory calibrated to ±1% accuracy.
Microcontroller Features
20 MHz Max. CPU Speed
35 Instructions
8 Level Hardware Stack
8 MHz Internal Oscillator – Selectable Output Range from 8 MHz to 31 kHz
24 I/O Pins – PIC16F913/916 Models
35 I/O Pins – PIC16F914/917 Models
53 I/O Pins – PIC16F946 Model Only
Power-On Reset (POR)
Brown-Out Reset (BOR)
Power-Up Timer (PWRT)
Oscillator Start-Up Timer (OST)
Watchdog Timer (WDT)
Programmable Low-Voltage Detect (PLVD)
In-Circuit Serial Programming (ICSP)
In-Circuit Debug (ICD)
35 Instructions
8 Level Hardware Stack
8 MHz Internal Oscillator – Selectable Output Range from 8 MHz to 31 kHz
24 I/O Pins – PIC16F913/916 Models
35 I/O Pins – PIC16F914/917 Models
53 I/O Pins – PIC16F946 Model Only
Power-On Reset (POR)
Brown-Out Reset (BOR)
Power-Up Timer (PWRT)
Oscillator Start-Up Timer (OST)
Watchdog Timer (WDT)
Programmable Low-Voltage Detect (PLVD)
In-Circuit Serial Programming (ICSP)
In-Circuit Debug (ICD)
Peripherals
Liquid Crystal Display (LCD) Module – PIC16F913/916 60 Segments, PIC16F914/917 96 Segments, PIC16F946 168 Segments
10-bit Analogue-to-Digital Converter (ADC) - PIC16F913/916 5 Channels, PIC16F914/917/946 8 Channels
Capture, Compare, PWM (CCP) Module – PIC16F913/916 x 1 Module, PIC16F914/917/946 x 2 Modules
Two Comparators
Two 8-bit Timers
One 16-bit Timer
Synchronous Serial Port (SSP) with I2C
Addressable Universal Synchronous Asynchronous Receiver Transmitter (AUSART)
10-bit Analogue-to-Digital Converter (ADC) - PIC16F913/916 5 Channels, PIC16F914/917/946 8 Channels
Capture, Compare, PWM (CCP) Module – PIC16F913/916 x 1 Module, PIC16F914/917/946 x 2 Modules
Two Comparators
Two 8-bit Timers
One 16-bit Timer
Synchronous Serial Port (SSP) with I2C
Addressable Universal Synchronous Asynchronous Receiver Transmitter (AUSART)
受注確定後にお客様専用製品として商品化されるため、発注後のキャンセル・返品はお受けできません。
仕様
特性 | |
---|---|
ファミリー名 | PIC16F |
パッケージタイプ | PDIP |
実装タイプ | スルーホール |
ピン数 | 40 |
デバイスコア | PIC |
データバス幅 | 8bit |
プログラムメモリサイズ | 14 kB、256 B |
最大周波数 | 20MHz |
RAMサイズ | 352 B |
USBチャンネル | 0 |
PWMユニット数 | 2 |
SPIチャンネル数 | 1 |
USARTチャネルの数 | 1 |
I2Cチャンネル数 | 1 |
標準動作供給電圧 | 4.5 → 5.5 V |
UARTチャンネル数 | 0 |
CANチャンネル数 | 0 |
インストラクションセットアーキテクチャ | RISC |
ADC数 | 8 x 10ビット |
高さ | 4.95mm |
ADCユニット数 | 1 |
動作温度 Min | -40 °C |
動作温度 Max | +85 °C |
長さ | 53.21mm |
幅 | 0.58インチ |
LINチャネルの数 | 0 |
イーサネットチャンネル数 | 0 |
PCIチャンネル数 | 0 |
最大イーサネットチャンネル数 | 0 |
プログラムメモリタイプ | フラッシュ |
PWM | 2 ( 10 ビット)( CCP ) |
寸法 | 2.095 x 0.58 x 0.195インチ |
