- RS品番:
- 235-4822
- メーカー型番:
- 197514 EASY-E4-AC-8RE1P
- メーカー/ブランド名:
- Eaton
- RS品番:
- 235-4822
- メーカー型番:
- 197514 EASY-E4-AC-8RE1P
- メーカー/ブランド名:
- Eaton
その他
詳細情報
Eaton EasyE4 Series Control Relay, Digital Input, Relay Output - 197514 EASY-E4-AC-8RE1P
This control relay from Eaton is designed to provide high-performance digital input and relay output specifications. The 24V DC voltage category makes it a reliable choice for various applications. With the EasyE4 series, this control relay ensures seamless operation and efficient functionality.
Features & Benefits
• Digital input capabilities for up to 4 inputs
• Relay output specifications for 4 outputs, ensuring efficient control
• EasyE4 series compatibility for enhanced integration
• Ethernet network connectivity for streamlined operation
• Voltage category of 24V DC for reliable performance
• Relay output specifications for 4 outputs, ensuring efficient control
• EasyE4 series compatibility for enhanced integration
• Ethernet network connectivity for streamlined operation
• Voltage category of 24V DC for reliable performance
Applications
• Input/output extension for easyE4 control relay
• Suitable for digital input/output expansions
• Suitable for digital input/output expansions
The I/O拡張は、100 → 240 V ac又は100 → 240 V dcの定格動作電圧を備えたeasyE4シリーズの制御リレー用です。cULus の場合、100-110 VDC はすべての VDC 仕様に適用されます。この拡張は、100 → 240 V ac又は100 → 240 V dc用の4つのデジタル入力と12 → 250 V ac又は12 → 220 V dc用の4つのリレー出力を提供します。接続はプッシュイン端子を使用して確立されます。
Can it be used for digital input/output expansions?
ソフトウェア: EasySoft-SWLIC / EasySoft 7
寸法: 35.5 x 90 x 58 mm
接続タイプ:プッシュイン端子
動作周囲温度: -25 → 55 ° C
保護タイプ( IEC/EN60529 、 EN50178 、 VBG 4 ) IP20
垂直取り付け位置
過電圧カテゴリ / 汚染レベル III/2
逆極性に対する保護
周波数: 50 / 60 ( ± 5 % ) Hz
寸法: 35.5 x 90 x 58 mm
接続タイプ:プッシュイン端子
動作周囲温度: -25 → 55 ° C
保護タイプ( IEC/EN60529 、 EN50178 、 VBG 4 ) IP20
垂直取り付け位置
過電圧カテゴリ / 汚染レベル III/2
逆極性に対する保護
周波数: 50 / 60 ( ± 5 % ) Hz
Yes, this control relay is designed for easyE4 series for seamless integration.
Will it work with Ethernet network connectivity?
Yes, the relay includes Ethernet network capabilities for efficient operation.
Is it compatible with easyE4 control relays?
Yes, the control relay is designed for easy integration with easyE4 series.
Can it handle a voltage category of 24V DC?
Yes, the control relay is suitable for applications requiring 24V DC voltage.
Does it offer digital input and relay output specifications?
Yes, the control relay provides digital input capabilities and efficient relay outputs.
備考
以前はMoellerとして知られていたEaton
仕様
特性 | |
---|---|
メーカーシリーズ | EasyE4 |
入力数 | 4 |
出力タイプ | リレー |
併用可能製品 | easyE4 |
電源電圧 | 264 V |
入力方式 | デジタル |
デジタル入力数 | 4 |
出力数 | 4 |
電圧カテゴリ | 24 V dc |
ネットワークタイプ | Ethernet |
デジタル出力数 | 4 |
幅 | 36mm |
アナログ出力数 | 0 |
アナログ入力数 | 0 |
実装タイプ | DIN Rail |
動作温度 Max | +55°C |
長さ | 90mm |
奥行き | 58mm |
ディスプレイ込み | なし |
代表規格 | CE |
寸法 | 58 x 90 x 36 mm |
動作温度 Min | -25°C |
