- RS品番:
- 422-8842
- メーカー型番:
- ZB6E1B
- メーカー/ブランド名:
- Schneider Electric
71 海外在庫あり - 通常4営業日でお届け
164 海外在庫あり - 通常5営業日でお届け
追加されました
単価: 購入単位は 個
¥1,027.00
(税抜)
¥1,129.70
(税込)
個 | 単価 |
1 + | ¥1,027.00 |
Better World
Better Worldシリーズは、環境にやさしく信頼できる製品を簡単にお選びいただける製品を取り揃えています。 詳しくはこちらをクリックしてください。
- RS品番:
- 422-8842
- メーカー型番:
- ZB6E1B
- メーカー/ブランド名:
- Schneider Electric
その他
RoHSステータス: 該当なし
- COO(原産国):
- FR
詳細情報
コンタクトブロック
ファストン固定具
Schneider Electric | Harmony XB6 Series (ZB6) | Contact Blocks & Light Blocks
Introducing the Harmony XB6 series of Contact Block by Schneider Electric. Specifically, the ZB6 range offers you reliability when you most need it. Tested under stringent scenarios & environments, the ZB6 range works incredibly well in many different scenarios and settings.
Features and benefits
• 1 NO contact type with <=250 V rated insulation voltage.
• 6 A cartridge fuse type gG conforming to EN/IEC 60947-5-1 providing you with excellent short-circuit protection to all surrounding components and users.
• 5,000,000 cycles of mechanical durability offering reliable, robust performance over a significant life span.
• Lightweight, easy to fit and configure. Easily removable and adjustable. Front mounting.
• Operating temperature of between -25 to 70 °C. Check the datasheet for further information.
• Schneider Green Premium product as standard across the XB4 Contact block range. Environmentally friendlier than alternatives, easy to dispose of safely.
• 18 month warranty period with Schneider Electric.
Protection ratings -
• IP65 conforming to IEC 60529 (protection against dust & water sprays from different directions)
• EN/IEC 60947-1, 60947-5-1 & 60947-5-4.
• UL 508 & CSA C22.2 No 14.
• Vibration resistance +/- 3 mm conforming to IEC 60068-2-6
• Shock resistance to 30/50gn dependant on the duration (see datasheet for spec).
• 6 A cartridge fuse type gG conforming to EN/IEC 60947-5-1 providing you with excellent short-circuit protection to all surrounding components and users.
• 5,000,000 cycles of mechanical durability offering reliable, robust performance over a significant life span.
• Lightweight, easy to fit and configure. Easily removable and adjustable. Front mounting.
• Operating temperature of between -25 to 70 °C. Check the datasheet for further information.
• Schneider Green Premium product as standard across the XB4 Contact block range. Environmentally friendlier than alternatives, easy to dispose of safely.
• 18 month warranty period with Schneider Electric.
Protection ratings -
• IP65 conforming to IEC 60529 (protection against dust & water sprays from different directions)
• EN/IEC 60947-1, 60947-5-1 & 60947-5-4.
• UL 508 & CSA C22.2 No 14.
• Vibration resistance +/- 3 mm conforming to IEC 60068-2-6
• Shock resistance to 30/50gn dependant on the duration (see datasheet for spec).
Applications -
• Used in conjunction with push buttons, signal controllers.
• Applicable uses within machine, chemical or marine applications
• Applicable uses within machine, chemical or marine applications
認可
UL; CSA
Schneider Electric ZB6 Harmony 16 mm
IP65シリーズの保護コンポーネントは、直径16 mmの穴に素早く、簡単に取り付けることができます。 必要なデバイスを組み立てるため、各部品を別途注文することができます。 スローブレークの正方向オープニングコンタクトや、ファストン / はんだ端子の付いたコンタクトブロックも用意しています。 定格: Ue 250 V ac、Ie 1.5 A、Ue 250 V dc、Ie 0.1 A、Io A Ith 動作温度: -25 → +70 °C
仕様
特性 | |
---|---|
ブロックのタイプ | コンタクトブロック |
シリーズ | Harmony XB6 |
接点構成 | 1NO |
Better World 製品 | あり |
Better World 認証 | Green Premium |
